[GB] Mammoth20 Pad

Drop @ 00:00AM GMT +8, Beijing Time, Jan. 14, 2022

Highlights

Sandblasted Diamond Cut Mammoth Weight
Special Gasket Structure
Aluminum, Magnet Knob
Bluetooth PCB supports VIA

Mammoth20 is using the same Bluetooth PCB solution with Mammoth75, it supports VIA, and works in wired and wireless mode. Check the demo video here.

Brief info

Typing angle: 6.5 degrees.
Front Height: 19.5 mm
Weight (unbuilt): 520 g
Case Material: Aluminum
Mounting Method: Gasket Mount
Package Weight: 1 kg

PCB Specifications:

Wired/Wireless Hot-swap PCB: 1.2mm thick
QMK / VIA support: Yes
In-switch LEDs: No
Underglow: No
ESD Protection: Yes

Kit Contents:

Top Case, Bottom Case (Anodized Aluminum)
PC Plate
WS Stabs 3×2U
Hotswap PCB, wired/wireless
PORON gaskets
PORON dampener between plate and PCB
PORON foam between PCB and switches
PORON foam under PCB
Aluminum knob
Magnet base
Encoder holder
Screws and rubber feet

Colors: E-white, Black, Navy, Violet

GB Time: January 14th, 2022 - Feb 7th, 2022
Estimated Delivery: July 2022 to Vendors

A standard sized, widely available LiPo battery is required for Bluetooth editions but it's not included with the kit. You can source it on your own.

Battery Specifications:
Mammoth75: 3543114
Mammoth20: 303450
JST1.25

Vendors
US: CannonKeys
Canada: Mech.land
Oceania:Daily Clack
Middle EU: Mykeyboard
UK:Proto[Typist]
Singapore: iLumkb
Philippines: Zion Studios
Malaysia:Rebult
Taiwan: Inpad
Thailand: Gamingplanet
Vietnam: Taobaosop
Rest of the world: Wuque StudioGB for Knobs

GB for Knobs

There will be a separate GB for the knobs after this GB. There will be community knobs and bespoke knobs. We will share some designs and let the community vote for community knob and accept personal knob design as bespoke one. The knob design vote will start before this GB ends.

Disclaimer

1. Please note that this is a group buy. Estimates are our best guesses, they're not guaranteed. Delays and setbacks may occur. DO NOT PURCHASE if you do not agree with the terms and conditions.

2. There will be a 4% fee on order cancellations and refunds after placing an order

3. Your payment method will be charged as soon as you place the order. There are no refunds or cancellation after the groupbuy ends.

Build Guide

Quality Disclaimer:

Micro scratches that are only visible in just the right angle of lighting, small scratches inside the keyboard case, or dents on the case that are not visible when the keyboard is fully built. These are normal and within our quality acceptance.
